Part no. | Diameter (mm) | Diameter (inch) | Plug Colour | Flute Length (mm) | Overall Length (mm) | Shank Diameter (mm) |
---|---|---|---|---|---|---|
2530-3.00x70 | 3 | 1/8 | YELLOW | 30 | 70 | 3 |
2530-4.00x75 | 4 | 5/32 | – | 40 | 75 | 4 |
2530-5.00x85 | 5 | 3/16 | WHITE | 45 | 85 | 5 |
2530-5.50x100 | 5.5 | 7/32 | RED | 50 | 100 | 5.5 |
2530-6.00x100 | 6 | 15/64 | – | 55 | 100 | 6 |
2530-6.50x100 | 6.5 | 1/4 | GREEN | 55 | 100 | 6.5 |
2530-7.00x100 | 7 | 9/32 | – | 55 | 100 | 7 |
2530-8.00x120 | 8 | 5/16 | BLUE | 60 | 120 | 8 |
2530-9.00x120 | 9 | 11/32 | – | 60 | 120 | 9 |
2530-10.00x120 | 10 | 3/8 | ORANGE | 65 | 120 | 10 |
